CASING FRACTAL DESIGN ATX TORRENT COMPACT TG DARK TINT (BLK) RGB

Specifications

• 3.5"/2.5" drive mounts
  1 (included)
• Dedicated 2.5" drive mounts
  3 (included)
• Expansion slots
  7
• Front interface
  1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio
• Total fan mounts
  2x 180 mm, 4x 140 mm, or 6x 120 mm (with included brackets)
• Front fan
  2x 180, 2x 140 mm, or 3x 120 mm (with included brackets) (2x Dynamic GP-18 included in standard versions, 2x Prisma AL-18 included in RGB version)
• Dust filters
  Front, Bottom
• Fixed cable straps
  Yes
• Cable routing grommets
  Yes
• Tool-less push-to-lock
  Side panels
• Captive thumbscrews
  HDD and SSD brackets
• Left side panel
  Steel or Tempered glass (RGB version: Tempered glass only)
• Right side panel
  Steel or Tempered glass (Solid/White RGB: Steel, TG/Black RGB: Tempered Glass)

Compatibility

• Motherboard compatibility
  E-ATX (up to 274 mm) / ATX / mATX / Mini-ITX / SSI-CEB
• Power supply type
  ATX
• PSU max length
  210 mm
• GPU max length
  330 mm with front fan mounted
• CPU cooler max height
  174 mm
• Rear fan
  1x 120 mm (not included)
• Bottom fan
  2x 180 mm (with mATX motherboard), 2x 140 mm, or 3x 120 mm
• Front radiator
  Up to 360x120/280x140 mm (360 mm front radiators (push / push-pull) supported up to a max length of 403 mm)
• Rear radiator
  120x120 mm
• Bottom radiator
  Up to 240x120/280x140 mm
• Cable routing space
  20 mm

Dimensions

• Case dimensions (LxWxH)
  450 x 222 x 467 mm
• Net weight
  BK TGD/TGL: 8.0 kg, WT TGC: 7.7 kg, BK Solid: 7.4 kg
• Package dimensions (LxWxH)
  535 x 306 x 574 mm
• Gross weight
  BK TGD/TGL: 9.7 kg, WT TGC: 9.5 kg, BK Solid: 9.2 kg

Other

• Package contents (non RGB versions)
  Torrent Compact, 2x Dynamic GP-18 fans, Accessory box, User manual, GPU support bracket
• Package contents (RGB version)
  Torrent Compact, 2x Prisma AL-18 fans, Accessory box, User manual, GPU support bracket
• EAN
  Black RGB TG Light Tint: 7340172702900, Black TG Dark Tint: 7340172702894, White TG Clear Tint: 7340172702917, Black Solid: 7340172702924, White RGB Clear Tint: 7340172705253
• UPC
  Black RGB TG Light Tint: 843276102906, Black TG Dark Tint: 843276102890, White TG Clear Tint: 843276102913, Black Solid: 843276102920, White RGB Clear Tint: 843276105259
• JAN
  Black RGB TG Light Tint: 4537694282925, Black TG Dark Tint: 4537694282918, White TG Clear Tint: 4537694282932, Black Solid: 4537694282949, White RGB Clear Tint: 4537694311724
• Product code
  Black RGB TG Light Tint: FD-C-TOR1C-02, Black TG Dark Tint: FD-C-TOR1C-01, White TG Clear Tint: FD-C-TOR1C-03, Black Solid: FD-C-TOR1C-04, White RGB Clear Tint: FD-C-TOR1C-05
