The HV PRO series complies features custom DC-DC design provides safety and power efficiency. With an 230V 80 Plusâ„¢ rating, both models deliver over 85% high efficiency and low noise levels thanks to its thermal control fan design, where a large 120mm fan takes care of cooling duties when required, making it excellent for situations that are sensitive to size and noise.
• Complies with ATX12 v2.52 & EPS12 v2.92
• Efficiency 85% @ typical Load
• Active PFC ≧ 0.9
• Hold up time > 17ms @80% Load
• +12V Single-Rail Design
• +5V &3.3V DC to DC Module Design
• 120mm Silent & long life Fan
• Complete Protections: OCP/OVP/OPP/SCP
Specifications:
Model FSP650-51AAC
Rated Output Power 650W
Form Factor ATX
80 PLUS Certification 230V EU Standard
Input Voltage 200-240V
Input Current 5A
Input Frequency 50-60Hz
PFC Active PFC
Efficiency 85%
Fan Type Sleeve Fan, 120mm
Dimensions(L x W x H) 150 x 140 x 86mm
Operation Temp. 100,000 Hrs
Protection OCP, OVP, OPP, SCP
FOR MORE DETAILS : https://www.fsplifestyle.com/PROP201003998/
