Force Series™ MP510 960GB M.2 SSD

The CORSAIR Force MP510 NVMe PCIe Gen3 x4 M.2 SSD provides extreme storage performance with blazing fast read speeds of up to 3,480MB/sec.

EXTREME STORAGE PERFORMANCE

All-new extreme data performance controller delivers up to 3,480MB/sec sequential read, and up to 3,000MB/s sequential write, for blazing fast read, write and response times.and maximum bandwidth.

HIGH-DENSITY 3D TLC NAND

Provides the ideal mix of performance, endurance and value to keep your drive performing at its best for years.



SSD Unformatted Capacity



960 GB

SSD Smart Support



Yes

Weight



0.055kg

SSD Interface



PCIe Gen 3.0 x4

SSD Max Sequential Read CDM



Up to 3,480MB/s

SSD Max Sequential Write CDM



Up to 3,000MB/s

Max Random Write QD32 IOMeter



Up to 570K IOPS

Max Random Read QD32 IOMeter



Up to 610K IOPS

Form Factor



M.2 2280

Dimensions



80mm x 22mm x 3mm

Application Consumer



Client

Weight



0.0082

NAND Technology



3D TLC NAND

Voltage



3.3V, +/- 5%

Endurance



1,700 TBW

TBW



1700

MTBF



1,800,000 Hours

DEVSLP



L1.2 < 2mW

Encryption



AES 256-bit Encryption

Storage Temperature



-40°C to +85°C

SSD Operating Temperature



0°C to +70°C

SSD Shock



1500 G

Storage Humidity



93% RH (40° C)

Operating Humidity



90% RH (40° C)

Vibration



20Hz~80Hz/1.52mm, 80Hz~2000Hz/20G
